Please post the modifications / corrections, if any. The sheet is protected and use password 123 to unprotect it. Do u have any excel file for 5000kl fuel storage tankĪ simple spread sheet to design (no analysis) the wall of a water tank subjected to bending and direct tension by WSM, as per IS 3370 (part 2) is enclosed. Ur excel work is very good but some link is not work. I want to design the UG tank of 25000 lit with width fixed to 2.8m and depth to 1.83m. I am not sure that the design is for the UG tank or tank rested on ground. find the attached excel sheet for the ground water tank. Contact: David Diehl or Gary Carson, 28.Posted: Sun 9:03 am Post subject: Re: water tank design excel sheet The latest version includes the latest addendum to the ninth edition of API-650 as well as the latest addendum to the second edition of API-653. Users are encouraged to suggest improvements that help their day to day usage of the software. Revisions incorporate additional capabilities addressing both technical and operational items.
The company engineering staff continuously maintains the program. Completed jobs can be converted to other units systems as client requirements dictate, without rerunning the analysis. The program also provides several standard units files, which, if not sufficient, can be used to generate other, custom units files.
A material data base editor is provided so the software can address additional materials not included in the code. Options affecting computations include 1988, 1993, 1994, 1995, 1996 material data bases, corroded nozzles, corroded hydrotest, corroded wind girder calculations, and wind pressures. The software also provides control options for everything from calculations to screen colors, allowing the customization of the software environment on a directory basis. Context sensitivity help provides instant technical assistance for each data field, with code references as often as possible. A menu driven scroll and select interface provides logical options when and where expected. For much less than it would cost to build an in-house spreadsheet application, the software delivers the features and stability typical of a COADE software product, including immediate, top-rate technical support.
a comprehensive engineering software program for PC-compatible computers that designs and analyzes oil storage tanks according to the latest API-650 and API-653 codes.
